Datasheet Switch Cisco C1300-12XT-2X
|
|
Specifications
|
|
Port
|
12 x 10 Gigabit copper ports
|
|
2 x 10 Gigabit SFP+
|
|
Console port
|
Cisco standard RJ-45 console port and USB Type C port
|
|
USB port
|
USB Type C port on the front panel of the switch for easy file and image management as well as console port
|
|
PoE
|
N/A
|
|
Performance
|
|
Switching capacity in Gigabits per second (Gbps)
|
280.0 Gbps
|
|
Capacity in Millions of Packets Per Second (mpps) (64-byte packets)
|
208.33 mpps
|
|
Hardware
|
|
CPU
|
ARM dual-core at 1.4 GHz
|
|
DRAM
|
1 GB DDR4
|
|
Flash
|
512 MB
|
|
Packet buffer
|
3 MB
|
|
Buttons
|
Reset button
|
|
Cabling type
|
Unshielded Twisted Pair (UTP) Category 5e or better for 1000BASE-T
|
|
LEDs
|
System, Link/Act, PoE, Speed
|
|
Feature
|
|
Spanning Tree Protocol
|
Standard 802.1d Spanning Tree support
|
|
Fast convergence using 802.1w (Rapid Spanning Tree [RSTP]), enabled by default
|
|
Multiple Spanning Tree instances using 802.1s (MSTP); 8 instances are supported
|
|
Per-VLAN Spanning Tree Plus (PVST+) and Rapid PVST+ (RPVST+); 126 instances are supported
|
|
Port grouping/link aggregation
|
Support for IEEE 802.3ad Link Aggregation Control Protocol (LACP)
|
|
● Up to 8 groups
|
|
● Up to 8 ports per group with 16 candidate ports for each (dynamic) 802.3ad link aggregation
|
|
VLAN
|
Support for up to 4093 VLANs simultaneously
|
|
Port-based and 802.1Q tag-based VLANs, MAC-based VLAN, protocol-based VLAN, IP subnet-based VLAN
|
|
Management VLAN
|
|
Private VLAN with promiscuous, isolated, and community port
|
|
Private VLAN Edge (PVE), also known as protected ports, with multiple uplinks
|
|
Guest VLAN, unauthenticated VLAN
|
|
Dynamic VLAN assignment via RADIUS server along with 802.1X client authentication
|
|
Customer premises equipment (CPE) VLAN
|
|
Auto surveillance VLAN (ASV)
|
|
Voice VLAN
|
Voice traffic is automatically assigned to a voice-specific VLAN and treated with appropriate levels of QoS. Voice Services Discovery Protocol (VSDP) delivers networkwide zero-touch deployment of voice endpoints and call control devices
|
|
Multicast TV VLAN
|
Multicast TV VLAN allows the single multicast VLAN to be shared in the network while subscribers remain in separate VLANs. This feature is also known as Multicast VLAN Registration (MVR)
|
|
IPv4 routing
|
Wire-speed routing of IPv4 packets
|
|
Up to 990 static routes and up to 128 IP interfaces
|
|
IPv6 routing
|
Wire-speed routing of IPv6 packets
|
|
Layer 3 interface
|
Configuration of a Layer 3 interface on a physical port, LAG, VLAN interface, or loopback interface
|
|
Routing Information Protocol (RIP) v2
|
Support for RIP v2 for dynamic routing
|
|
Policy-Based Routing (PBR)
|
Flexible routing control to direct packets to a different next hop based on an IPv4 or IPv6 Access Control List (ACL)
|
|
DHCP server
|
Switch functions as an IPv4 DHCP server, serving IP addresses for multiple DHCP pools or scopes
|
|
Support for DHCP options
|
|
Environmental
|
|
Unit dimensions (W x H x D)
|
300 x 268 x 44 mm
|
|
Unit weight
|
2.64 kg
|
|
Power
|
100-240V 50-60 Hz
|
|
Certification
|
UL (UL 62368), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A
|
|
Operating temperature
|
23° to 122°F (-5° to 50°C)
|
|
Storage temperature
|
-13° to 158°F (-25° to 70°C)
|
|
Operating humidity
|
10% to 90%, relative, noncondensing
|
|
Storage humidity
|
10% to 90%, relative, noncondensing
|
|
Fan (number)
|
1
|
|
MTBF at 25°C (hours)
|
1,198,404
|
